The Basics of React Native Animations

Animations are important to create a great impact on the experience of the User

React Native provides two animation systems:

1. Animated for granular and interactive control of specific values,

2. LayoutAnimation for animated global layout transactions.

Animated API​

The Animated API is designed to concisely express a wide variety of interesting animation and interaction patterns in a very performant way. Animated focuses on declarative relationships between inputs and outputs, with configurable transforms in between, and start/stop methods to control time-based animation execution.

Animated exports six animatable component types:

1. View
2. Text
3. Image
4. ScrollView
5. FlatList
6. SectionList

But you can also create your own animatable component using Animated.createAnimatedComponent()

Configuring animations​

Animations are heavily configurable. Custom and predefined easing functions, delays, durations, decay factors, spring constants, and more can all be tweaked depending on the type of animation.

Animated provides several animation types, the most commonly used one Animated.timing(). It supports animating a value over time using one of the various predefined easing functions, or you can use your own. Easing functions are typically used in animation to convey gradual acceleration and deceleration of objects.

By default, timing will use an easeInOut curve that conveys gradual acceleration to full speed and concludes by gradually decelerating to a stop. You can specify a different easing function by passing an easing parameter. Custom duration or even a delay before the animation starts is also supported.

For example, if we want to create a 2-second long animation of an object that slightly backs up before moving to its final position:

Animated.timing(this.state.xPosition, {
  toValue: 100,
  easing: Easing.back(),
  duration: 2000
}).start();

Take a look at the Configuring animations section of the Animated API reference to learn more about all the config parameters supported by the built-in animations.

Composing animations​

Animations can be combined and played in sequence or in parallel. Sequential animations can play immediately after the previous animation has finished or start after a specified delay. The Animated API provides several methods, such as sequence() and delay(), each of which takes an array of animations to execute and automatically calls start()/stop() as needed.

For example, the following animation coasts to a stop, then it springs back while twirling in parallel:

Animated.sequence([
  // decay, then spring to start
  Animated.decay(position, {
    // coast to a stop
    velocity: { x: gestureState.vx, y: gestureState.vy },
// velocity from gesture release
    deceleration: 0.997
  }),
  Animated.parallel([
    // after decay, in parallel:
    Animated.spring(position, {
      toValue: { x: 0, y: 0 } // return to start
    }),
    Animated.timing(twirl, {
      // and twirl
      toValue: 360
    })
  ])
]).start(); // start the sequence group

If one animation is stopped or interrupted, then all other animations in the group are also stopped. Animated.parallel has a stopTogether option that can be set to false to disable this.

You can find a full list of composition methods in the Composing animations section of the Animated API reference.

Combining animated values​

To make a new animated value, you can combine two animated values via addition, multiplication, and division, or modulocombine two animated values via addition, multiplication, division, or modulo to make a new animated value.

There are some cases where an animated value needs to invert another animated value for calculation. An example is inverting a scale (2x → 0.5x):

const valueA = new Animated.Value(1);
const valueB= Animated.divide(1, valueA);
Animated.spring(valueA, {
  toValue: 2
}).start();

Interpolation​

Each property can be run through an interpolation first. An interpolation maps input ranges to output ranges, typically using a linear interpolation but also supports easing functions. By default, it will extrapolate the curve beyond the ranges given, but you can also have it clamp the output value.

A basic mapping to convert

0–1 range to 0–100 range would be:

value.interpolate({
  inputRange: [0, 1],
  outputRange: [0, 100]
});

For example, you may want to think about your Animated.Value as going from 0 to 1, but animate the position from 150px to 0px and the opacity from 0 to 1. This can be done by modifying style from the example above like so:

style={{
    opacity: this.state.fadeAnim, // Binds directly
    transform: [{
      translateY: this.state.fadeAnim.interpolate({
        inputRange: [0, 1],
        outputRange: [150, 0]  // 0 : 150, 0.5 : 75, 1 : 0
      }),
    }],
  }}

interpolate() supports multiple range segments as well, which is handy for defining dead zones and other handy tricks. For example, to get a negation relationship at -300 that goes to 0 at -100, then back up to 1 at 0, and then back down to zero at 100 followed by a dead-zone that remains at 0 for everything beyond that, you could do:

value.interpolate({
  inputRange: [-300, -100, 0, 100, 101],
  outputRange: [300, 0, 1, 0, 0]
});

Which would map like so:

Input | Output
------|-------
  -400|    450
  -300|    300
  -200|    150
  -100|      0
   -50|    0.5
     0|      1
    50|    0.5
   100|      0
   101|      0
   200|      0

interpolate() also supports mapping to strings, allowing you to animate colors as well as values with units. For example, if you wanted to animate a rotation you could do:

value.interpolate({
  inputRange: [0, 360],
  outputRange: ['0deg', '360deg']
});

interpolate() also supports arbitrary easing functions, many of which are already implemented in the Easing module. interpolate() also has configurable behavior for extrapolating the outputRange. You can set the extrapolation by setting the extrapolate, extrapolateLeft, or extrapolateRight options. The default value is extend but you can use clamp to prevent the output value from exceeding outputRange.

Tracking dynamic values​

Animated values can also track other values by setting the toValue of an animation to another animated value instead of a plain number. For example, a "Chat Heads" animation like the one used by Messenger on Android could be implemented with a spring() pinned on another animated value, or with timing() and a duration of 0 for rigid tracking. They can also be composed with interpolations:

Animated.spring(follower, { toValue: leader }).start();
Animated.timing(opacity, {
  toValue: pan.x.interpolate({
    inputRange: [0, 300],
    outputRange: [1, 0]
  })
}).start();

The leader and follower animated values would be implemented using Animated.ValueXY(). ValueXY is a handy way to deal with 2D interactions, such as panning or dragging. It is a basic wrapper that contains two Animated.Value instances and some helper functions that call through to them, making ValueXY a drop-in replacement for Value in many cases. It allows us to track both x and y values in the example above.

Tracking gestures​

Gestures, like panning or scrolling, and other events can map directly to animated values using Animated.event. This is done with a structured map syntax so that values can be extracted from complex event objects. The first level is an array to allow mapping across multiple arguments , and that array contains nested objects.

For example, when working with horizontal scrolling gestures, you would do the following in order to map event.nativeEvent.contentOffset.x to scrollX

onScroll={Animated.event(
   // scrollX = e.nativeEvent.contentOffset.x
   [{ nativeEvent: {
        contentOffset: {
          x: scrollX
        }
      }
    }]
 )}

The following example implements a horizontal scrolling carousel where the scroll position indicators are animated using the Animated.event used in the ScrollView

ScrollView with Animated Event Example​

When using PanResponder, you could use the following code to extract the x and y positions from gestureState.dx and gestureState.dy. We use a null in the first position of the array, as we are only interested in the second argument passed to the PanResponder handler, which is the gestureState.

onPanResponderMove={Animated.event(
  [null, // ignore the native event
  // extract dx and dy from gestureState
  // like 'pan.x = gestureState.dx, pan.y = gestureState.dy'
  {dx: pan.x, dy: pan.y}
])}

PanResponder with Animated Event Example​

Responding to the current animation value​

You may notice that there is no clear way to read the current value while animating. This is because the value may only be known in the native runtime due to optimizations. If you need to run JavaScript in response to the current value, there are two approaches:

• spring.stopAnimation(callback) will stop the animation and invoke callback with the final value. This is useful when making gesture transitions.
• spring.addListener(callback) will invoke callback asynchronously while the animation is running, providing a recent value. This is useful for triggering state changes, for example snapping a bobble to a new option as the user drags it closer, because these larger state changes are less sensitive to a few frames of lag compared to continuous gestures like panning which need to run at 60 fps.

Animated is designed to be fully serializable so that animations can be run in a high performance way, independent of the normal JavaScript event loop. This does influence the API, so keep that in mind when it seems a little trickier to do something compared to a fully synchronous system. Check out Animated.Value.addListener as a way to work around some of these limitations, but use it sparingly since it might have performance implications in the future.

Using the native driver​

The Animated API is designed to be serializable. By using the native driver, we send everything about the animation to native before starting the animation, allowing native code to perform the animation on the UI thread without having to go through the bridge on every frame. Once the animation has started, the JS thread can be blocked without affecting the animation.

Using the native driver for normal animations is straightforward. You can add useNativeDriver: true to the animation config when starting it.

Animated.timing(this.state.animatedValue, {
  toValue: 1,
  duration: 500,
  useNativeDriver: true // <-- Add this
}).start();

Animated values are only compatible with one driver so if you use native driver when starting an animation on a value, make sure every animation on that value also uses the native driver.

The native driver also works with Animated.event. This is especially useful for animations that follow the scroll position as without the native driver, the animation will always run a frame behind the gesture due to the async nature of React Native.

<Animated.ScrollView // <-- Use the Animated ScrollView wrapper
  scrollEventThrottle={1} // <-- Use 1 here to make sure no events are ever missed
  onScroll={Animated.event(
    [
      {
        nativeEvent: {
          contentOffset: { y: this.state.animatedValue }
        }
      }
    ],
    { useNativeDriver: true } // <-- Add this
  )}>
  {content}
</Animated.ScrollView>

You can see the native driver in action by running the RNTester app, then loading the Native Animated Example. You can also take a look at the source code to learn how these examples were produced.

Caveats​

Not everything you can do with Animated is currently supported by the native driver. The main limitation is that you can only animate non-layout properties: things like transform and opacity will work, but Flexbox and position properties will not. When using Animated.event, it will only work with direct events and not bubbling events. This means it does not work with PanResponder but does work with things like ScrollView#onScroll.

When an animation is running, it can prevent VirtualizedList components from rendering more rows. If you need to run a long or looping animation while the user is scrolling through a list, you can use isInteraction: false in your animation's config to prevent this issue.

Bear in mind​

While using transform styles such as rotateY, rotateX, and others ensure the transform style perspective is in place. At this time some animations may not render on Android without it. Example below.

<Animated.View
  style={{
    transform: [
      { scale: this.state.scale },
      { rotateY: this.state.rotateY },
      { perspective: 1000 } // without this line this Animation will not render on Android while working fine on iOS
    ]
  }}
/>

LayoutAnimation API​

LayoutAnimation allows you to globally configure create and update animations that will be used for all views in the next render/layout cycle. This is useful for doing Flexbox layout updates without bothering to measure or calculate specific properties in order to animate them directly, and is especially useful when layout changes may affect ancestors, for example a "see more" expansion that also increases the size of the parent and pushes down the row below which would otherwise require explicit coordination between the components in order to animate them all in sync.

Note that although LayoutAnimation is very powerful and can be quite useful, it provides much less control than Animated and other animation libraries, so you may need to use another approach if you can't get LayoutAnimation to do what you want.

Note that in order to get this to work on Android you need to set the following flags via UIManager:

UIManager.setLayoutAnimationEnabledExperimental &&
  UIManager.setLayoutAnimationEnabledExperimental(true);

This example uses a preset value, you can customize the animations as you need, see LayoutAnimation.js for more information.​

requestAnimationFrame​

requestAnimationFrame is a polyfill from the browser that you might be familiar with. It accepts a function as its only argument and calls that function before the next repaint. It is an essential building block for animations that underlies all of the JavaScript-based animation APIs. In general, you shouldn't need to call this yourself - the animation APIs will manage frame updates for you.

setNativeProps​

As mentioned in the Direct Manipulation section, setNativeProps allows us to modify properties of native-backed components (components that are actually backed by native views, unlike composite components) directly, without having to setState and re-render the component hierarchy.

We could use this in the Rebound example to update the scale — this might be helpful if the component that we are updating is deeply nested and hasn’t been optimized with shouldComponentUpdate.

If you find your animations with dropping frames (performing below 60 frames per second), look into using setNativeProps or shouldComponentUpdate to optimize them. Or you could run the animations on the UI thread rather than the JavaScript thread with the useNativeDriver option. You may also want to defer any computationally intensive work until after animations are complete, using the InteractionManager. You can monitor the frame rate by using the In-App Developer Menu "FPS Monitor" tool.

Hope this Article is helpful!!
